Download PDF >> Auto Start Battery - SH4s1p-12V 100Ah LiFePo4 Battery
Jump Starter Battery/Car Battery Booster/Portable Car Battery Charger
| Product Code | SH4s1p-100Ah (apanese series) | SH4s1p-100Ah (European series) |
| Code Img |
|  |
| Performance parameters | ||
| Nominal Voltage | 12.8V | 12.8V |
| Nominal Capacity | 100Ah | 100Ah |
| Energy | 1280Wh | 1280Wh |
| Internal Resistance | <30mQ | <30m |
| Cycle Life | 24000 cycles @1C 100%DOD | Q24000 cycles @1C 100%DOD |
| Months Self Discharge | <3% | <3% |
| Efficiency of Charge | 100% @0.5C | 100% @0.5C |
| Efficiency of Discharge | 96~99% @1C | 96~99% @1C |
| Standard Charge | ||
| Charge Voltage | 14.6+0.2V | 14.6+0.2V0.2C to 14.6V, then 14.6V,charge |
| Charge Mode | 0.2C to 14.6V, then 14.6V,charge current to 0.02C (CC/CV) | current to 0.02C (CC/CV) |
| Charge Current | 20A | 20A |
| Battery Charging Time | about 3h | about 3h |
| Standard Discharge | ||
| Charge Cut-off voltage | 10V+0.2V | 10V+0.2V |
| Max Continuous discharge Current | 100A | 100A |
| Max. Cranking Amps | 1000A | 1000A |
| Environmental | ||
| High cold cranking Amps | 1000 CCA(-20C) | 1000 CCA(-20C) |
| Charge Temperature | 0°C to 45°C(32F to 113F) @60+25% Relative Humidity | |
| Discharge Temperature | -20°C to 60°C(-4F to 140F) @60+25% Relative Humidity | |
| Storage Temperature | 0°C to 40°C(32F to 104F) @60+25% Relative Humidity | |
| Mechanical | ||
| Water Dust Resistant | IP65 | IP30 |
| Cell & Method | 3.2V100AH-4S1P | 3.2V100AH-4S1P |
| Plastic Case | ABS | Plastic case |
| Dimensions (in./mm.) | 230*175*162/215mm | 355*175*190mm |
| Weight (lbs./kg.) | 12kg | 12kg |
| BMS | Smart BMS 4S100A | |
